Wireless, Handheld Tympanometers
Otowave 102-4 Screening Tympanometry
This wireless handheld Tympanometer with large screen provides 226 Hz probe tone impedance measurement including 4 acoustic reflex frequencies. Results are stored internally (up to 30 records). All data can be transferred to a PC via the MedRx software module and IR dongle.
Features:
- Fast and accurate middle ear measurements
- Intuitive and ergonomic design
- Large LCD graphics display
- Programmable ipsi reflex tests
- Optional portable printer and PC interface
- Multiple language options
- Internal Memory
- PC connectivity to Noah applications with optional IrDA port
- Compact, lightweight, and portable
Contact Us For More Information
Get a Quote
Downloads
Download the Otowave 102 Tympanometer Manuals, Data Sheets, Computer Specs, etc. here in PDF format
Accessories, etc.
Product Specs
Analysis Performed: Compliance peak level (in ml), Ear canal volume (ECV) at 200 daPa, Ipsilateral reflex
Probe Tone Levels: 226 Hz ± 2%, 85 dB SPL ± 2 dB. Over range 0.2 ml to 5 ml
Pressure Levels: +200 daPa to – 400 daPa. ± 10 daPa
Ear Volume Measurement Range: 0.2 ml to 5 ml ± 0.1 ml or ± 10% (whichever is larger) over entire range
Reflex Tone Levels: 500 Hz, 1000 Hz, 2000 Hz, 4000 Hz Frequency ± 0.1%, Configurable over range 85 dB to 100 dB HL (programmable in 5 – 10 dB steps)
Reflex Measurement Range: 0.01 ml to 0.5 ml ± 0.01 ml configurable in 0.01 ml steps
Power: Battery specification: 4 Alkaline AA cells or 4 NiMH rechargeable
Dimensions: Approx. 21 cm x 8 cm x 4 cm (L x W x H)
Weight: 380 g
